产品规格参数:
型号 | LINCam25 | LINCam40 |
有效面积直径 | 25mm | 40mm |
位置分辨率 | 1000 x 1000 pixels | |
时间分辨率 | ≤50ps FWHM | |
显微镜支架 | C-mount | T-mount |
外壳尺寸 | 145×78×50mm | 145×100×53mm |
重量 | 500g | 600g |
制冷 | 低噪声空气或者液体制冷 |
Acquisition system | |
Maximal count rate, MHz | 1 |
Dead time, ns | 400 |
Timing | |
Method | TAC + ADC |
Minimum bin width, ps | ≤ 1,4 |
Electrical resolution, ps | 6 |
Number of bins | 4096 |
Reference input | Positive or negative NIM |
Time tagging resolution, ns | 10 |
Computer interface | USB 2.0 |
Operating system | Windows 7/10 64 Bit |
光谱灵敏度
